Key Features
l Efficient Bubble Removal——Adopts hot air circulation combined with high-pressure air technology, effectively preventing cold air pockets inside the chamber. The continuous air circulation ensures strong heat penetration, eliminates dead zones, and guarantees consistent debubbling results across all products .
l Three Flexible Process Modes——Supports multiple operating sequences to suit different TP lamination requirements: ① Pressure before temperature rise; ② Simultaneous pressure and temperature rise; ③ Temperature rise before pressurization .
l Precise Temperature & Pressure Control——Utilizes PID temperature control with ±1.0–2.0°C accuracy and ±0.01–0.05Mpa pressure control precision, ensuring stable and repeatable process conditions. Temperature range: room temperature to 100°C (operating <85°C); Maximum pressure: 0.8–1.0Mpa .
l Uniform Heating & Air Circulation——Features a magnetic drive coupling fan system with specially designed fan blades, ensuring even temperature distribution throughout the chamber. The bottom heating element combined with axial flow fan creates a top-to-bottom circulation, eliminating cold spots and ensuring uniform debubbling .
l Intelligent PLC & HMI Control——Equipped with programmable logic controller and 5–10 inch color touchscreen interface. Operators can set parameters, monitor real-time temperature/pressure curves, and store multiple recipes for different TP products. Fully automatic operation from start to completion .
l Robust Safety System——Designed with dual mechanical and electrical safety interlocks. Includes over-temperature protection, over-pressure protection with automatic pressure relief valves, and emergency stop functions. Manufactured in accordance with GB-150 pressure vessel standards with inspection certifications available .
Technical Parameters
l Chamber Material SUS304 Stainless Steel (anti-rust)
l Effective Chamber Size Customizable (e.g., φ500×1000mm, φ800×1200mm, φ900×1200mm, φ1000×1200mm)
l Maximum Pressure 0.8 – 1.0 Mpa (design pressure)
l Temperature Range RT – 100°C (operating temperature <85°C)
l Temperature Control Accuracy ±1.0 – 2.0°C
l Temperature Uniformity ±2.0 – 3.0°C
l Pressure Control Accuracy ±0.01 – 0.05 Mpa
l Power Supply AC 380V, 3-phase, 50/60Hz, 6–15kVA
l Control System PLC with 5–10 inch color HMI touchscreen
l Door Locking Method Flange rotary locking mechanism with one-step operation
