Key Features
l Ultra-Fast Charging Speed Supports charging power up to 480kW, capable of adding up to 400km of range in 10–15 minutes (depending on vehicle model and battery capacity) .
l Wide Voltage Output Range Output voltage range of 150V–1000V, compatible with both low-voltage (400V) and high-voltage (800V) vehicle platforms, ensuring future-proof compatibility .
l Intelligent Power Distribution Dual-gun models support dynamic power distribution, automatically adjusting power allocation based on vehicle demand and charger utilization to maximize charging efficiency .
l High Conversion Efficiency Utilizes high-efficiency power modules with peak efficiency up to 96%, reducing energy loss and operating costs .
l User-Friendly Interface Equipped with a 7–21.5 inch color touchscreen, providing real-time charging data, QR code payment, and user guidance. Supports mobile app integration for remote monitoring and payment .
l Comprehensive Safety Protection Integrated protections include overvoltage, undervoltage, overcurrent, short circuit, leakage, overtemperature, and emergency stop. IP54-rated enclosure ensures reliable outdoor operation .
l Multi-Standard Compatibility Supports GB/T, CCS1, CCS2, CHAdeMO, and other international charging standards (configurable), meeting diverse vehicle requirements in global markets .
Technical Parameters
l Power Rating 30kW – 480kW (configurable by module combination)
l Input Voltage AC 380V ±20%, three-phase, 50/60Hz
l Output Voltage Range DC 150V – 1000V
l Output Current Range 0 – 600A (depending on model and configuration)
l Charging Standards GB/T, CCS1, CCS2, CHAdeMO (selectable)
l Communication Protocols OCPP 1.6 / 2.0, Modbus TCP, CAN bus
l Display 7 – 21.5 inch color touchscreen
l Payment Methods QR code scanning, RFID card, mobile APP (configurable)
l Protection Level IP54 (indoor/outdoor)
l Cooling Method Forced air cooling / Liquid cooling (for high-power models)
l Operating Temperature -20°C – 50°C (de-rating above 50°C)
l Dimensions (W×D×H) 650×450×1600 mm (30–60kW) / 800×700×1900 mm (120–480kW, customizable)
l Mounting Method Floor-standing / Wall-mounted (low-power models)
