Key Features
l High Durability & Weather Resistance Constructed with high-strength thermoplastic materials (PC/ABS) resistant to UV radiation, impact, and chemicals. Sealed to IP55 or IP67, ensuring reliable outdoor operation in rain, dust, and extreme temperatures (-30°C to +50°C) .
l Safe & Ergonomic Design Lightweight, ergonomic handle reduces operator fatigue. Integrated safety interlock prevents disconnection under load. Optional button-lock or trigger-lock mechanisms enhance safety during charging .
l High-Power Charging Support Supports both AC charging (up to 43kW, 32A per phase) and DC fast charging (up to 500kW, 600A) with liquid-cooled cable options for ultra-fast charging applications .
l Integrated Communication Built-in resistor and temperature sensor (PT1000/NTC) enable real-time temperature monitoring and control pilot (CP) communication between vehicle and charger for safe and efficient charging .
l Multi-Standard Compatibility Available in all major international standards: GB/T (China), Type 1 (SAE J1772, North America), Type 2 (IEC 62196-2, Europe), CCS1/CCS2, CHAdeMO, and Tesla (NACS) .
l Customizable Cable Length & Color Offered in cable lengths from 3m to 15m (customizable), with various color options and branding possibilities to suit different installation environments and corporate identity requirements .
Technical Parameters
l Parameter AC Charging Cable DC Charging Cable
l Applicable Standards GB/T (AC), Type 1, Type 2 GB/T (DC), CCS1, CCS2, CHAdeMO, NACS
l Max. Current 16A – 80A (single-phase / three-phase) 80A – 600A (with optional liquid cooling)
l Max. Voltage AC 250V / 480V DC 1000V / 1500V
l Max. Power 7.2kW – 43kW 80kW – 500kW+
l Number of Pins 5 pins (Type 1) / 7 pins (Type 2, GB/T AC) 9 pins (GB/T DC) / 7 pins (CCS) / 10 pins (CHAdeMO)
l Cable Jacket Material TPE / TPU / PVC (UL94 V-0) TPE / TPU / PVC (UL94 V-0)
l Contact Material Copper alloy with silver/nickel plating Copper alloy with silver/nickel plating
l Terminal Temperature Monitoring NTC / PT1000 sensor NTC / PT1000 sensor
l Protection Level IP55 (mated) / IP54 (unmated) IP55 (mated) / IP54 (unmated)
l Operating Temperature -30°C – +50°C -30°C – +50°C
l Flammability Rating UL94 V-0 UL94 V-0
l Mechanical Lifespan ≥ 10,000 insertion/withdrawal cycles ≥ 10,000 insertion/withdrawal cycles
